Ceph Pacific All Flash
- Highly available storage cluster 3-way replication
- Block Storage (Ideal for VMs and containers)
- Object storage with Swift and S3 API
- Fault tolerance (up to 2 failed disks without data loss)
- Self-healing and self-managing
- Complete: hardware, software, configuration, & support
- Block storage – 5028MB /s| 1,258K IOPS
- S3 Object storage – 5029MB/s | 12.409k objects/s
-
$AUD $206,535.00
*RRP Pricing*To View Channel Discounts Please Login
- Ex Tax: $206,535.00
Ceph Pacific All Flash Appliance
Hyperscalers has developed a fully supported all-flash-storage solution based on Ceph Pacific to address the object, block, and file storage needs of service providers looking to achieve hyperscale capabilities to deploying super-fast storage quickly, reliably and at a fraction of historical costs.
About Ceph
Ceph (16.2.7/ Pacific) is a freely available software-defined storage solution (supported by Hyperscalers) that implements a distributed storage cluster to provide interfaces for object-, block- and file-level storage. Ceph aims primarily for completely distributed operation without a single point of failure. Ceph storage manages data replication and is generally quite fault tolerant. As a result of its design, the system is both self-healing and self-managing
Features
• Highly available distributed storage cluster with 3-way replication
• Block Storage (Ideal for VMs and containers)
• Object storage with Swift and S3 API
• Fault tolerance (up to 2 failed disks without data loss)
• Self-healing and self-managing
• Complete with hardware, software, configuration, set-up and support.
Storage speed
• Block storage – 5028MB /s| 1,258K IOPS
• S3 Object storage – 5029MB/s | 12.409k objects/s
Architecture
Ceph pacific is deployable across many types of Hyperscalers’ storage servers including S5S, S5P, S5X, S5K as well as 25/40/100 Gb/s data network speeds.
Download the Whitepaper in the Downloads section
Server | Number of nodes | Nodes | CPU | RAM | NIC Mezz | Storage card | PCIe NIC | Storage Drives | OS |
S5S | 4 + 1 | Mgmt (S100-X1S1N) | E3-1220 v3 x1 | 8/1600x2 | Null | Null | Intel 82599ES 10GBe | 240 GB Samsung NVMe | Ubuntu 18.04 |
| | Node 1 | Intel Scalable Processor Family | 16/2933x4 units | Intel 82599ES x8 | 3108 (IT/JBOD mode) | Solarflare 9120 10GBe | 120 GB Intel NVMe, 1.96 TB HGST x2 | Ubuntu 18.04 |
| | Node 2 | Intel Scalable Processor Family | 16/2933x4 units | Intel 82599ES x8 | 3108 (IT/JBOD mode) | Solarflare 9120 10GBe | 120 GB Intel NVMe, 1.96 TB HGST x2 | Ubuntu 18.04 |
| | Node 3 | Intel Scalable Processor Family | 16/2933x4 units | Intel 82599ES x8 | 3108 (IT/JBOD mode) | Solarflare 9120 10GBe | 120 GB Intel NVMe, 1.96 TB HGST x2 | Ubuntu 18.04 |
Title | Version | Date | Size | |
---|---|---|---|---|
Ceph Pacific Whitepaper | 1 | 01-02-2022 | 777kb |
Tags: support, ceph, OSD, hyperscale, pacific
